FdueG fournit ses produits dans des boxes avec un degré de protection IP66 qui garantissent aux transformateurs et aux réacteurs l’installation et le fonctionnement en toute sécurité dans n’importe quel environnement.
Pour tous les boxes sont fournis sur demande accessoires tels que ventilateurs, interrupteurs, systèmes de contrôle de la température, roues. Les boxes avec un degré plus élevé de protection IP44 permettent l’installation des produits FdueG dans lieux avec atmosphère difficile et peuvent être équipés avec des systèmes de ventilation forcée, air-eau ou air-air.
L’air de ventilation du transformateur est indépendant de l’air présent à l’extérieur de la surface, et l’échange de chaleur a lieu à travers des systèmes d’eau ou d’air pulsé. Ces systèmes améliorent considérablement les performances en réduisant la taille et permettant l’installation de produits imprégné sous vide, même dans des conditions de fonctionnement difficiles.
Pour grands renseignements: IP class protection
Box de protection jusqu’à IP 66
According to the standard CEI EN 60529 (CEI 70-1) the degree of protection of the casing for electrical equipment is specified. It is characterized by the abbreviation « IP » and by two characteristic figures; the first digit gives an indication on the protection against accidental contacts and against foreign bodies, while the second specifies the behavior with respect to water exposure.
Tableau de degré de protection IP
IP.. | First digit: Access of solid objects |
Second digit: Access of liquids |
0 | No protection | No protection |
1 | Protected against solid objects over 50mm e.g. hands, large tools. | Protected against vertically falling drops of water or condensation. |
2 | Protected against solid objects over 12.5mm e.g. hands, large tools. | Protected against falling drops of water, at an angle up to 15° from vertical. |
3 | Protected against solid objects over 2.5mm e.g. wire, small tools. | Protected against sprays of water from any direction, at an angle up to 60° from vertical. |
4 | Protected against solid objects over 1.0mm e.g. wires. | Protected against splash water from any direction. |
5 | Limited protection against dust ingress. (no harmful deposit) |
Protected against low pressure water jets from any direction. Limited access permitted. |
6 | Totally protected against dust ingress. | Protected against high pressure water jets from any direction. Limited access permitted. |
7 | N/A | Protected against short periods of immersion in water. |
8 | N/A | Protected against long, durable periods of immersion in water. |
9 | N/A | Protected against close-range high pressure, high temperature spray downs. |
